- Commodity name: SCM2 SERIES
- Commodity ID: SCM2 SERIES
The SCM2 series are with two back to back impellers, it is use for high head values but if hard to reach with single impeller centrifugal pump, Suitable for civil and industrial uses to pump clean water and chemically non-aggressive liquid. Particularly be used for increasing the supply pressure, feeding boilers and loading extremely, These pumps should be installed in a covered area, protected against the weather.
-
- Pump body: Cast iron
- Impeller: Double brass impeller
- Motor: Closed, externally ventilated
- Insulation class: B(Class F if required)
- Protection class: IP44/IP54
- Duty: Continuously rated
- Mechanical seal: φ16, φ18, φ25 silicon carbide/graphite
- Shaft: Stainless steelAISI 420
The normal power standard is 220V 50Hz single phase.
Three phase 220/380V/50Hz, 220/440V/60Hz,
Single phase 230V, 240V, 127V, 110V,115V/60Hz models are available on request
-
DIMENSIONS
TYPE
DIMENSIONS(mm)
a c f h H1 H2 w n n1 g s JETS-40
97 195 378 230 99 153 104 130 94 7 11 JETS-60
97 195 378 230 99 153 104 130 94 7 11 JETS-80
97 195 378 230 99 153 104 130 94 7 11 JETS-100
97 195 378 230 99 153 104 130 94 7 11 JETS-110
97 195 378 230 99 153 104 130 94 7 11 TYPE power Ampere
1~220V
R.P.M Q.Max
(I/min)
H.Max
(m)
S.Head
(m)
Pipe Dia L*W*H
(mm)
N.W
(kg)
HP KW JETS-40
0.45 0.33 2.7 2850 40 35 9 1"*1" 420*220*220 6.5 JETS-60
0.5 0.37 3 45 38 8.3 JETS-80
0.75 0.55 3.6 50 45 9.4 JETS-100
1 0.75 4.8 60 48 10.4 JETS-110
1.2 0.9 5.6 70 48 11.0
