- Commodity name: WQP SERIES
- Commodity ID: WQP SERIES
WQ series submersible sewage pump is mainly comprised of three parts: pump, mechanical seals and motor. Pump is at the lower part of sewage pump, and the structure is impeller and shell.
Motor located at the upper part of the motor pump, which is the single phase or three- phase electric motor. Mechanical seals are between pump and motor and it is a kind of double end mechanical seals, "O"rings are applied in all static joints of the submersible pump.
-
- Pump body: Cast iron
- Impeller: Cast iron
- Motor: Closed, externally ventilated
- Insulation class: B(Class F if required)
- Protection class: IP68
- Duty: Continuously rated
- Mechanical seal: φ 12,φ 16 ceramic steatite/graphite
- Shaft: Stainless steel AISI 420
The normal power standard is 220V 50Hz single phase.
Three phase 220/380V/50Hz, 220/440V/60Hz,
Single phase 230V, 240V, 127V, 110V, 115V/60Hz
models are available on request
-
TYPE power Ampere
R.P.M Q.Max
(I/min)
H.Max
(m)
Pipe Dia L*W*H
(mm)
N.W
(kg)
HP KW 1~220V 3~380V WQ-050
0.5
0.37 2.7 - 2850 100 6.5 1" 360*300*480 20.3
WQ-075
0.75
0.55 3.6 - 200 6.5 1¼" 27
WQ-100
1.5
0.75 4.5 - 250 10 1½" 28.2
WQ-150A/T
1.5
1.1 7.5 2.7 400 8 2" 450*370*580 29.1
WQ-150B/T
1.5
1.1 7.5 2.7 480 12 29.1
WQ-200A/T
2
1.5 9.6 3.5 480 10 2½" 20.2
WQ-200B/T
2
1.5 9.6 3.5 540 16 30.2
WQ-300A/T
3
2.2 13.5 5.0 1000 12 3" 31.5
WQ-300B/T
3
2.2 13.5 5.0 1200 19 31.5
WQP-150B/T
1.5 1.1 7.5 2.7 480 10 2" 600*370*1000 46.9
WQP-200B/T
2 1.5 9.6 3.5 540 14 1½" 48
WQP-300B/T
3 2.2 13.5 5.0 1200 17 3" 49.3
